Libreboot provides libre boot firmware (based on coreboot) that initializes the hardware (e.g. memory controller, CPU, peripherals) on specific Intel/AMD x86 and ARM targets, which then starts a bootloader for your operating system (Linux/BSD).
Go to file
Leah Rowe 665840b2b9 coreboot/dell9020*_12mb: Disable IOMMU by default
Needed to make graphics cards work. Turn it on if you're using
only the Intel GPU.

With IOMMU *enabled*, graphics cards do not work reliably at all.
The cause still needs to be investigated, but the symptoms are
graphical corruption on the screen, and Xorg usually crashes.
In some cases (on some cards), TTYs can still be used; the payload
can still be used reliably, on a graphics card, but Xorg fails to
work properly.

This could be a bug in Linux drivers, instead of anything that
coreboot does (not yet tested in factory BIOS).

Leaving it off by default will ensure reliable operation on all
setups, whether an iGPU or dGPU is used.

Signed-off-by: Leah Rowe <>
2024-03-02 23:13:43 +00:00
config coreboot/dell9020*_12mb: Disable IOMMU by default 2024-03-02 23:13:43 +00:00
include also reset xtree/tree_depend here 2024-01-26 11:15:23 +00:00
script Libreboot 20240225 2024-02-25 12:53:16 +00:00
util remove remaining flashrom remnants (use flashprog) 2024-01-27 22:37:39 +00:00
.gitignore put docs under docs/ in releases (not src/docs/) 2023-11-06 00:04:13 +00:00
COPYING libreboot! 2021-05-18 13:56:12 +01:00 remove remaining flashrom remnants (use flashprog) 2024-01-27 22:37:39 +00:00
build lbmk scripts: shorter code lines 2023-12-24 09:04:36 +00:00
projectname update README 2021-05-18 14:05:01 +01:00
update remove build symlink, rename lbmk to build 2023-10-06 02:12:52 +01:00
vendor lbmk: use 2-level directory structure in script/ 2023-10-20 01:00:38 +01:00


Find libreboot documentation at

The libreboot project provides libre boot firmware that initializes the hardware (e.g. memory controller, CPU, peripherals) on specific Intel/AMD x86 and ARM targets, which then starts a bootloader for your operating system. Linux/BSD are well-supported. It replaces proprietary BIOS/UEFI firmware. Help is available via #libreboot IRC on Libera IRC.

Why use Libreboot?

Why should you use libreboot?

Libreboot gives you freedoms that you otherwise can't get with most other boot firmware. It's extremely powerful and configurable for many use cases.

You have rights. The right to privacy, freedom of thought, freedom of speech and the right to read. In this context, Libreboot gives you these rights. Your freedom matters. Right to repair matters. Many people use proprietary (non-libre) boot firmware, even if they use a libre OS. Proprietary firmware often contains backdoors (more info on the FAQ), and it and can be buggy. The libreboot project was founded in December 2013, with the express purpose of making coreboot firmware accessible for non-technical users.

The libreboot project uses coreboot for hardware initialisation. Coreboot is notoriously difficult to install for most non-technical users; it handles only basic initialization and jumps to a separate payload program (e.g. GRUB, Tianocore), which must also be configured. The libreboot software solves this problem; it is a coreboot distribution with an automated build system (named lbmk) that builds complete ROM images, for more robust installation. Documentation is provided.

How does Libreboot differ from coreboot?

In the same way that Debian is a GNU+Linux distribution, libreboot is a coreboot distribution. If you want to build a ROM image from scratch, you otherwise have to perform expert-level configuration of coreboot, GRUB and whatever other software you need, to prepare the ROM image. With libreboot, you can literally download from Git or a source archive, and run make, and it will build entire ROM images. An automated build system, named lbmk (Libreboot MaKe), builds these ROM images automatically, without any user input or intervention required. Configuration has already been performed in advance.

If you were to build regular coreboot, without using libreboot's automated build system, it would require a lot more intervention and decent technical knowledge to produce a working configuration.

Regular binary releases of libreboot provide these ROM images pre-compiled, and you can simply install them, with no special knowledge or skill except the ability to follow installation instructions and run commands BSD/Linux.

Project goals

  • Support as much hardware as possible! Libreboot aims to eventually have maintainers for every board supported by coreboot, at every point in time.
  • Make coreboot easy to use. Coreboot is notoriously difficult to install, due to an overall lack of user-focused documentation and support. Most people will simply give up before attempting to install coreboot. Libreboot's automated build system and user-friendly installation instructions solves this problem.

Libreboot attempts to bridge this divide by providing a build system automating much of the coreboot image creation and customization. Secondly, the project produces documentation aimed at non-technical users. Thirdly, the project attempts to provide excellent user support via IRC.

Libreboot already comes with a payload (GRUB), flashprog and other needed parts. Everything is fully integrated, in a way where most of the complicated steps that are otherwise required, are instead done for the user in advance.

You can download ROM images for your libreboot system and install them without having to build anything from source. If, however, you are interested in building your own image, the build system makes it relatively easy to do so.

Not a coreboot fork!

Libreboot is not a fork of coreboot. Every so often, the project re-bases on the latest version of coreboot, with the number of custom patches in use minimized. Tested, stable (static) releases are then provided in Libreboot, based on specific coreboot revisions.

How to help

You can check bugs listed on the bug tracker.

If you spot a bug and have a fix, the website has instructions for how to send patches, and you can also report it. Also, this entire website is written in Markdown and hosted in a separate repository where you can send patches.

Any and all development discussion and user support are all done on the IRC channel. More information is on


It's just a README file. This README file is released under the terms of the Creative Commons Zero license, version 1.0 of the license, which you can read here:
